YZY 7 Inch TFT LCD Module With 1024x600 Resolution MIPI Interface Capacitive Touch Screen 500 Nits Brightness And Wide Viewing Angle Display

Wholesale YZY 7 Inch TFT LCD Module With 1024x600 Resolution MIPI Interface Capacitive Touch Screen 500 Nits Brightness And Wide Viewing Angle Display from china suppliers

Operating Temperature : -20℃-+70℃

Delivery Time : 14-60days

Display Size : 7.0 Inch

Model Number : YVT0700PKM-S1

Display Type : a-Si TFT-LCD, Transmissive, Normally White

Resolution : 1024*600dots

Price : $5.52-6.9/pieces

Packaging Details : 20*15*5cm

Backlight Type : 27 pcs White LED (3S × 9P), 9.6V/180mA

Supply Ability : 10000pieces

Brightness : 500cd/m²

Payment Terms : T/T

Type : TFT-LCD Module

Place of Origin : Guangdong, China

Outline Dimension : 164.9*100*5.5mm

MOQ : 500

Interface : MIPI

Active Area : 154.2144*85.92mm

Brand Name : YZY

Contact Now

YZY 7.0 Inch TFT LCD Module 1024×600 MIPI Interface 500 Nits 800:1 Contrast Capacitive Touch Screen Wide Viewing Angle Industrial Display (YVT0700PKM-S1)

YZY 7 Inch TFT LCD Module With 1024x600 Resolution MIPI Interface Capacitive Touch Screen 500 Nits Brightness And Wide Viewing Angle Display

7.0" TFT LCD Module Highlights:

*Model: YVT0700PKM-S1 (SH07ZJWS50L-7010T-BA-D)

*7.0 inch display, 1024×600 resolution

*500 nits brightness, 800:1 contrast ratio

*85° all-direction wide viewing angle (ALL O'Clock)

*MIPI DSI interface, 30-pin FPC

*Integrated capacitive touch panel (CTP)

*16.7M colors, 45%-50% color gamut

*27 white LEDs backlight, 9.6V/180mA

*RoHS compliant, 12-month warranty

YVT0700PKM-S1 — 7.0 Inch 1024×600 MIPI TFT LCD Module with Capacitive Touch
Parameter	Value
Customer Model No.	YVT0700PKM-S1
Module No. / Part Number	SH07ZJWS50L-7010T-BA-D
LCD Type	a-Si TFT-LCD, Transmissive, Normally White
Display Size	7.0 Inch Diagonal
Resolution	1024 × 600 dots (1024×RGB×600)
Display Colors	16.7M (24-bit RGB)
Pixel Configuration	RGB Vertical Stripe
Pixel Pitch	0.1506 × 0.1432 mm
Active Area (W × H)	154.21 × 85.92 mm
Outline Dimension (W × H × T)	164.9 × 100.0 × 5.5 mm (with CTP)
Brightness (Typ.)	500 cd/m² (nits)
Contrast Ratio (Typ.)	800 : 1
Luminance Uniformity (Min./Typ.)	75% / 80%
Viewing Angle (Cr≥10)	85° all directions (Left/Right/Up/Down, ALL O'Clock)
Response Time (Typ./Max)	25 ms / 40 ms (Tr+Tf)
Color Gamut	45% (Min.) / 50% (Typ.)
Interface Type	MIPI DSI Interface, 30-pin FPC
Touch Support	Integrated capacitive touch panel (CTP)
Logic Power Supply (VDD)	1.8V (Typ.), 1.7V ~ 1.9V
Analog Power Supply (AVDD)	10V (Typ.), 9.0V ~ 11V
Gate Voltage (VGH/VGL)	VGH 19V (Typ.), VGL -8V (Typ.)
Backlight Type	27 pcs White LED (3-series × 9-parallel)
Backlight Voltage (Typ.)	9.6V (9.0V ~ 10.8V)
Backlight Current (Typ.)	180 mA (20mA per string)
Operating Temperature	-20°C ~ +70°C
Storage Temperature	-30°C ~ +80°C
Viewing Direction	ALL O'Clock (FREE, wide viewing angle)
Compliance	RoHS

Why Choose YZY:

*15 years of LCD screen production experience

*Strong engineer team and 24 hours online service

*Products are RoHS, REACH and CE certified

*Products have a 12-month warranty period

*High quality & low price, high reliability, long-term supply

*Customization available: brightness, interface, touch panel

Frequently Asked Questions (FAQ)

Q1: What is the lead time for the YVT0700PKM-S1 7.0-inch 1024×600 TFT LCD module?
A: Standard samples ship within 3-5 working days. Bulk orders typically take 15-25 working days depending on quantity and customization requirements.

Q2: What is the resolution and brightness of this 7.0 inch TFT LCD display?
A: This YVT0700PKM-S1 module features 1024×600 resolution and 500 nits typical brightness, with 800:1 contrast ratio and 85° wide viewing angle, delivering clear visuals for industrial control, HMI, and embedded display applications.

Q3: What interface does this 7.0 inch TFT LCD module use?
A: This module uses a MIPI DSI interface on a 30-pin FPC connector, supporting high-speed serial data transmission. Compatible with most ARM, Raspberry Pi, and embedded processors that support MIPI DSI output.

Q4: Does this 1024×600 TFT display support a touch screen?
A: Yes! This module comes with an integrated capacitive touch panel (CTP), supporting multi-touch gestures for intuitive user interaction. Ideal for HMI, smart home, and industrial control applications requiring touch input.

Q5: What are the backlight specifications for this 7.0 inch module?
A: The backlight consists of 27 white LEDs arranged in 3-series × 9-parallel configuration. Typical backlight voltage is 9.6V (range 9.0V~10.8V) and current is 180mA (20mA per string). A constant current LED driver is recommended.

Q6: What power supplies are required for this module?
A: This module requires VDD 1.8V (digital), AVDD 10V (analog), VGH 19V (gate ON), and VGL -8V (gate OFF). Please note the digital supply is 1.8V, not 3.3V. We provide application circuit guidance and reference designs.

Q7: What applications is this 7.0 inch 1024×600 TFT LCD suitable for?
A: Ideal for industrial control panels, HMI, smart home devices, medical equipment, automotive displays, POS terminals, kiosks, IoT devices, and embedded applications requiring a 7.0 inch MIPI interface display with capacitive touch and 1024×600 resolution.

Q8: Do you offer customization and what is the warranty policy?
A: Yes. We support customized brightness, FPC cable length and shape, backlight voltage, viewing direction, touch panel configuration, and cover glass (AG/AR/AF). MOQ applies for custom versions. All modules come with a 12-month warranty and lifetime technical support.
